--- title: When to Use a Diaphragm Seal vs. an Isolation Ring description: Learn when to use diaphragm seals versus isolation rings to protect your instruments from clogging and corrosion in various industrial applications. image: https://blog.ashcroft.com/hubfs/Seal_ISO_2024_BLOG_V2.jpg --- [Skip to main content](https://blog.ashcroft.com/diaphragm-seal-vs.-isolation-ring#maincontent) Select Region - [US & Canada](https://ashcroft.com) - [Europe](https://ashcroft.eu/) - [China](http://www.ashcroft.com.cn/) - [Mexico & Central America](http://www.ashcroft.com.mx/) - [South America](https://ashcroftsudamericana.com/) - [Brazil](https://ashcroft.com.br/) Login - [Distributor Extranet](https://extranet.ashcroft.com/) - [Product Configurator](https://www.ashcroft.com/my-account/) [Careers](https://www.ashcroft.com/careers) [Contact](https://www.ashcroft.com/contact/) [![ashcroft-logo-lg-2](https://blog.ashcroft.com/hs-fs/hubfs/ashcroft-logo-lg-2.png?width=261&height=60&name=ashcroft-logo-lg-2.png) ![ashcroft-logo-white](https://blog.ashcroft.com/hubfs/assets/images/ashcroft-logo-white.svg)](https://www.ashcroft.com/) Products Pressure Instruments - [Pressure Gauges](https://www.ashcroft.com/products/pressure/pressure-gauges) - [Pressure Switches](https://www.ashcroft.com/products/pressure/pressure-switches) - [Pressure Sensors (Transducers/Transmitters)](https://www.ashcroft.com/products/pressure/pressure-sensors) - [Diaphragm Seals-Isolators](https://www.ashcroft.com/products/pressure/diaphragm-seals-and-isolators) - [Accessories](https://www.ashcroft.com/products/pressure/accessories) - [SMART Transmitter Assemblies](https://www.ashcroft.com/products/pressure/smart-transmitter-assemblies) Temperature Instruments - [Thermometers](https://www.ashcroft.com/products/temperature/thermometers) - [Thermowells](https://www.ashcroft.com/products/temperature/thermowells) - [Temperature Switches](https://www.ashcroft.com/products/temperature/temperature-switches) - [RTDs](https://www.ashcroft.com/products/temperature/rtds) - [Thermocouples](https://www.ashcroft.com/products/temperature/thermocouples) - [Temperature Transmitters](https://www.ashcroft.com/products/temperature/temperature-transmitters/) - [MultiPoint Temperature Sensors](https://www.ashcroft.com/products/temperature/multipoint-temperature-sensors/) - [OEM Temperature Sensors](https://www.ashcroft.com/products/temperature/oem-temperature-sensors) Test Instruments - [Calibrators](https://www.ashcroft.com/products/test-instruments/calibrators/) - [Hand Pumps-Controllers](https://www.ashcroft.com/products/test-instruments/hand-pumps-and-controllers/) - [Hydraulic Testers](https://www.ashcroft.com/products/test-instruments/hydraulic-testers/) - [Test Gauges](https://www.ashcroft.com/products/test-instruments/test-gauges/) Helpful Tools - [Product Documentation](https://www.ashcroft.com/learn/product-documentation/) - [Product & Quality Certifications](https://www.ashcroft.com/about/quality-certifications/) - [Material Selector & Corrosion Guide](https://www.ashcroft.com/webtools/materialselector/) - [Unit Converter](https://www.ashcroft.com/webtools/calculatoruom/) - [Wake Frequency Calculator](https://www.ashcroft.com/webtools/calculatorwf/) - [FAQs](https://www.ashcroft.com/faq/) Keep your critical equipment and processes running with reliable pressure and temperature measurements. [Configure Product Part Number](https://www.ashcroft.com/product-configurator) [Get a Quote](https://www.ashcroft.com/quote) Industries Process Industry Overview - [Solutions for the Process Industry](https://www.ashcroft.com/solutions/process-industry-instrumentation) - [Large Projects/EPC](https://www.ashcroft.com/solutions/process-industry-instrumentation/engineering-procurement-construction-large-projects/) - [Critical Application Solution Experts](https://www.ashcroft.com/solutions/process-industry-instrumentation/critical-application-solution-experts/) - [Distributor Locator](https://www.ashcroft.com/ashcroft-distributors/) Process Industry Solutions - [Chemical & Petrochemical](https://www.ashcroft.com/solutions/process-industry-instrumentation/chemical-process-instrumentation/) - [Food & Beverage](https://www.ashcroft.com/solutions/process-industry-instrumentation-sensors/food-beverage/) - [Metals & Minerals](https://www.ashcroft.com/solutions/process-industry-instrumentation/mining-instruments/) - [Oil & Gas](https://www.ashcroft.com/solutions/process-industry-instrumentation/oil-gas-instrumentation/) - [Pharmaceutical & Biotech](https://www.ashcroft.com/solutions/process-industry-instrumentation/pharmaceutical-and-biotechnology-application-solutions/) - [Power](https://www.ashcroft.com/solutions/process-industry-instrumentation/power-plant-instrumentation/) - [Water & Wastewater](https://www.ashcroft.com/solutions/process-industry-instrumentation/instruments-used-in-water-treatment-plant/) Industrial/OEM Markets Overview - [Solutions for Industrial OEM](https://www.ashcroft.com/solutions/industrial-oem/) - [Custom Engineered Solutions (CES)](https://www.ashcroft.com/solutions/industrial-oem-custom-engineered-solutions/) Industrial/OEM Markets - [HVAC/R](https://www.ashcroft.com/solutions/industrial-oem/hvac-refrigeration-equipment/) - [Hydrogen & Alternative Energu](https://www.ashcroft.com/solutions/industrial-oem/hydrogen-alternative-energy/) - [Industrial Equipment Manufacturer](https://www.ashcroft.com/solutions/industrial-oem/industrial-equipment-manufacturer-supplier/) - [Medical Health & Safety](https://www.ashcroft.com/solutions/industrial-oem/medical-biotechnology-instruments/) - [Process Equipment Manufacturer](https://www.ashcroft.com/solutions/industrial-oem/process-equipment-manufacturer/) - [Semiconductor](https://www.ashcroft.com/solutions/industrial-oem/ultra-high-purity-gas-delivery-semiconductor-manufacturing/) - [Vehicles](https://www.ashcroft.com/solutions/industrial-oem/vehicles-working-machines/) Resources - [Product Documentations](https://www.ashcroft.com/learn/product-documentation/) - [Educational Resources](https://www.ashcroft.com/learn/resource-center/) About - [About](https://www.ashcroft.com/about/) - [Corporate Responsibility](https://www.ashcroft.com/about/corporate-responsibility/) - [Code of Conduct](https://www.ashcroft.com/about/corporate-responsibility/code-of-conduct/) - [Trade Compliance](https://www.ashcroft.com/about/corporate-responsibility/trade-compliance/) - [Product Stewardship](https://www.ashcroft.com/about/corporate-responsibility/product-stewardship/) - [Company News & Events](https://www.ashcroft.com/news-events/) - [Leadership Team](https://www.ashcroft.com/about/leadership/) - [Brands & Trademarks](https://www.ashcroft.com/about/brands-trademarks/) - [Careers](https://www.ashcroft.com/careers/) [Get a Quote](https://sales.ashcroft.com/quote) Products Products [Pressure Instruments](https://www.ashcroft.com) Pressure Instruments [Pressure Gauges](https://www.ashcroft.com/products/pressure/pressure-gauges) [Pressure Switches](https://www.ashcroft.com/products/pressure/pressure-switches) [Pressure Sensors (Transducers/Transmitters)](https://www.ashcroft.com/products/pressure/pressure-sensors) [Diaphragm Seals-Isolators](https://www.ashcroft.com/products/pressure/diaphragm-seals-and-isolators) [Accessories](https://www.ashcroft.com/products/pressure/accessories) [SMART Transmitter Assemblies](https://www.ashcroft.com/products/pressure/smart-transmitter-assemblies) [Temperature Instruments](https://www.ashcroft.com) Temperature Instruments [Thermometers](https://www.ashcroft.com/products/temperature/thermometers) [Thermowells](https://www.ashcroft.com/products/temperature/thermowells) [Temperature Switches](https://www.ashcroft.com/products/temperature/temperature-switches) [RTDs](https://www.ashcroft.com/products/temperature/rtds) [Thermocouples](https://www.ashcroft.com/products/temperature/thermocouples) [Temperature Transmitters](https://www.ashcroft.com/products/temperature/temperature-transmitters/) [MultiPoint Temperature Sensors](https://www.ashcroft.com/products/temperature/multipoint-temperature-sensors/) [OEM Temperature Sensors](https://www.ashcroft.com/products/temperature/oem-temperature-sensors) [Test Instruments](https://www.impactplus.com) Test Instruments [Calibrators](https://www.ashcroft.com/products/test-instruments/calibrators/) [Hand Pumps-Controllers](https://www.ashcroft.com/products/test-instruments/hand-pumps-and-controllers/) [Hydraulic Testers](https://www.ashcroft.com/products/test-instruments/hydraulic-testers/) [Test Gauges](https://www.ashcroft.com/products/test-instruments/test-gauges/) [Helpful Tools](https://www.impactplus.com) Helpful Tools [Product Documentation](https://www.ashcroft.com/learn/product-documentation/) [Product & Quality Certifications](https://www.ashcroft.com/about/quality-certifications/) [Material Selector & Corrosion Guide](https://www.ashcroft.com/webtools/materialselector/) [Unit Converter](https://www.ashcroft.com/webtools/calculatoruom/) [Wake Frequency Calculator](https://www.ashcroft.com/webtools/calculatorwf/) [FAQs](https://www.ashcroft.com/faq/) Industries Industries [Process Industry Overview](https://www.impactplus.com) Process Industry Overview [Solutions for the Process Industry](https://www.ashcroft.com/solutions/process-industry-instrumentation) [Large Projects/EPC](https://www.ashcroft.com/solutions/process-industry-instrumentation/engineering-procurement-construction-large-projects/) [Critical Application Solution Experts](https://www.ashcroft.com/solutions/process-industry-instrumentation/critical-application-solution-experts/) [Distributor Locator](https://www.ashcroft.com/ashcroft-distributors/) [Process Industry Solutions](https://www.impactplus.com) Process Industry Solutions [Chemical & Petrochemical](https://www.ashcroft.com/solutions/process-industry-instrumentation/chemical-process-instrumentation/) [Food & Beverage](https://www.ashcroft.com/solutions/process-industry-instrumentation-sensors/food-beverage/) [Metals & Minerals](https://www.ashcroft.com/solutions/process-industry-instrumentation/mining-instruments/) [Oil & Gas](https://www.ashcroft.com/solutions/process-industry-instrumentation/oil-gas-instrumentation/) [Pharmaceutical & Biotech](https://www.ashcroft.com/solutions/process-industry-instrumentation/pharmaceutical-and-biotechnology-application-solutions/) [Power](https://www.ashcroft.com/solutions/process-industry-instrumentation/power-plant-instrumentation/) [Water & Wastewater](https://www.ashcroft.com/solutions/process-industry-instrumentation/instruments-used-in-water-treatment-plant/) [Industrial/OEM Markets Overview](https://www.impactplus.com) Industrial/OEM Markets Overview [Solutions for Industrial OEM](https://www.ashcroft.com/solutions/industrial-oem/) [Custom Engineered Solutions (CES)](https://www.ashcroft.com/solutions/industrial-oem-custom-engineered-solutions/) [Industrial/OEM Markets](https://www.impactplus.com) Industrial/OEM Markets [HVAC/R](https://www.ashcroft.com/solutions/industrial-oem/hvac-refrigeration-equipment/) [Hydrogen & Alternative Energu](https://www.ashcroft.com/solutions/industrial-oem/hydrogen-alternative-energy/) [Industrial Equipment Manufacturer](https://www.ashcroft.com/solutions/industrial-oem/industrial-equipment-manufacturer-supplier/) [Medical Health & Safety](https://www.ashcroft.com/solutions/industrial-oem/medical-biotechnology-instruments/) [Process Equipment Manufacturer](https://www.ashcroft.com/solutions/industrial-oem/process-equipment-manufacturer/) [Semiconductor](https://www.ashcroft.com/solutions/industrial-oem/ultra-high-purity-gas-delivery-semiconductor-manufacturing/) [Vehicles](https://www.ashcroft.com/solutions/industrial-oem/vehicles-working-machines/) Resources Resources [Product Documentations](https://www.ashcroft.com/learn/product-documentation/) [Educational Resources](https://www.ashcroft.com/learn/resource-center/) About About [About](https://www.ashcroft.com/about/) [Corporate Responsibility](https://www.ashcroft.com/about/corporate-responsibility/) [Code of Conduct](https://www.ashcroft.com/about/corporate-responsibility/code-of-conduct/) [Trade Compliance](https://www.ashcroft.com/about/corporate-responsibility/trade-compliance/) [Product Stewardship](https://www.ashcroft.com/about/corporate-responsibility/product-stewardship/) [Company News & Events](https://www.ashcroft.com/news-events/) [Leadership Team](https://www.ashcroft.com/about/leadership/) [Brands & Trademarks](https://www.ashcroft.com/about/brands-trademarks/) [Careers](https://www.ashcroft.com/careers/) Select Region Select Region [US & Canada](https://ashcroft.com) [Europe](https://ashcroft.eu/) [China](http://www.ashcroft.com.cn/) [Mexico & Central America](http://www.ashcroft.com.mx/) [South America](https://ashcroftsudamericana.com/) [Brazil](https://ashcroft.com.br/) Login Login [Distributor Extranet](https://extranet.ashcroft.com/) [Product Configurator](https://www.ashcroft.com/my-account/) [Careers](https://www.ashcroft.com/careers) [Contact](https://www.ashcroft.com/contact/) [Get a Quote](https://sales.ashcroft.com/quote) [«  View All Articles](https://blog.ashcroft.com/) ![Hope Karimi-Sheumaker, Territory Sales Manager's headshot](https://blog.ashcroft.com/hs-fs/hubfs/Hope%20Karimi.jpg?width=50&height=50&name=Hope%20Karimi.jpg) **By:** [Hope Karimi-Sheumaker](https://blog.ashcroft.com/author/hope-karimi-sheumaker) Territory Sales Manager **Published on:** October 23rd, 2024 **Topics:** [Isolation Rings](https://blog.ashcroft.com/topic/isolation-rings) [water & wastewater](https://blog.ashcroft.com/topic/water-wastewater) [diaphragm seals](https://blog.ashcroft.com/topic/diaphragm-seals) **Share:** [mailto:?subject=When+to+Use+a+Diaphragm+Seal+vs.+an+Isolation+Ring&body=https://blog.ashcroft.com/diaphragm-seal-vs.-isolation-ring](mailto:?subject=When+to+Use+a+Diaphragm+Seal+vs.+an+Isolation+Ring&body=https://blog.ashcroft.com/diaphragm-seal-vs.-isolation-ring) Subscribe Never miss a blog post! Subscribe now and get the latest blog posts delivered straight to your inbox. # When to Use a Diaphragm Seal vs. an Isolation Ring Print/Save as PDF ![Hope Karimi-Sheumaker, Territory Sales Manager's headshot](https://blog.ashcroft.com/hs-fs/hubfs/Hope%20Karimi.jpg?width=50&height=50&name=Hope%20Karimi.jpg) **By:** [Hope Karimi-Sheumaker](https://blog.ashcroft.com/author/hope-karimi-sheumaker) Territory Sales Manager **Published on:** October 23rd, 2024 **Topics:** [Isolation Rings](https://blog.ashcroft.com/topic/isolation-rings) [water & wastewater](https://blog.ashcroft.com/topic/water-wastewater) [diaphragm seals](https://blog.ashcroft.com/topic/diaphragm-seals) **Share:** [mailto:?subject=When+to+Use+a+Diaphragm+Seal+vs.+an+Isolation+Ring&body=https://blog.ashcroft.com/diaphragm-seal-vs.-isolation-ring](mailto:?subject=When+to+Use+a+Diaphragm+Seal+vs.+an+Isolation+Ring&body=https://blog.ashcroft.com/diaphragm-seal-vs.-isolation-ring) ![](https://blog.ashcroft.com/hs-fs/hubfs/Seal_ISO_2024_BLOG_V2.jpg?width=1600&height=534&name=Seal_ISO_2024_BLOG_V2.jpg) *This article was originally published on April 24, 2023, and updated on October 23, 2024.* Diaphragm seals and isolation rings are both integral to the safe and efficient operation of your application. Whether it is a chemical plant, water treatment plant or mining facility, these isolators are used throughout the plant to protect instrumentation from harsh process media. But what’s the difference between these two instruments? And, when would you use a diaphragm seal instead of an isolation ring? Throughout my career, I’ve heard this question a lot. Not just from the customers in my territory, but also from product distributors during any of the product training seminars that I conduct for Ashcroft.  Continue reading to learn the basic differences between diaphragm seals and isolation rings, which you would use one over the other in specific applications and why. You will also see links to additional resources to learn more.  ## What is a Diaphragm Seal? A [diaphragm seal](https://www.ashcroft.com/products/pressure/diaphragm-seals-and-isolators?pageNumber=1&postTypes=product&postsPerPage=12&sortType=menu_order&sortOrder=ASC&tax-pa_connection-type=1304%2C1306%2C1301%2C1396) is a device installed between the process media and one or more instruments. It includes a thin, flexible membrane (the diaphragm) that isolates an instrument(s) from the process media. They are a vital component for applications that involve harsh, corrosive chemicals or media with particulates that could clog the sensing element of the instrument assembly. Using a quality diaphragm seal can provide a leak-tight and corrosion-resistant seal between a pressure instrument and your process. The applications in which you would use a diaphragm seal depend on several factors. *Figure 1: Common styles of diaphragm seals. * ![Diaphragm Seal Types-2](https://blog.ashcroft.com/hs-fs/hubfs/Diaphragm%20Seal%20Types-2.jpg?width=485&height=516&name=Diaphragm%20Seal%20Types-2.jpg) ### When to Use a Diaphragm Seal Diaphragm seals can be used for corrosive media or media that will have a small amount of particulates. If it’s too labor-intensive for the customer to flush out the inside of the lower housing of the seal, the seal won’t be suitable for the application. However, before you decide on a seal, consider the size of the solids. Think of sand, golf balls and tennis balls. If the percentage of solids is on the lower side and the size of solids is small (like the size of sand particles, for example), a diaphragm seal may be appropriate. The following diaphragm seal designs are less prone to clogging: - [Inline and saddle diaphragm seals](https://www.ashcroft.com/products/pressure/diaphragm-seals-and-isolators/?pageNumber=1&postTypes=product&postsPerPage=12&sortType=menu_order&sortOrder=ASC&tax-pa_connection-type=1306). These styles are mounted in line with the process piping and used in applications where continuous flow is required. - Seals with a [flushing port.](https://blog.ashcroft.com/flushing-connection-on-diaphragm-seal) This feature helps avoid clogging, but if the particulate is too rough/ abrasive, it can damage the metallic diaphragm. Both diaphragm seals and isolation rings can address clogging and corrosion concerns. But, you must consider what wetted material to use by considering what kind of particulates are present in the application (and if they are abrasive), what kind of metal or elastomer you need and its media compatibility. ## What is an Isolation Ring? An[isolation ring](https://www.ashcroft.com/products/pressure/diaphragm-seals-and-isolators/?pageNumber=1&postTypes=product&postsPerPage=12&sortType=menu_order&sortOrder=ASC&tax-pa_seal-features=1302) is another type of isolator that helps protect pressure-measuring instruments from exposure to certain processes. They isolate instruments such as pressure gauges, switches and high-priced transmitters from the process material to prevent damage. [![Water and Wastewater Industry Solutions](https://no-cache.hubspot.com/cta/default/4021582/ae4c2301-80fc-441f-8f61-49b42722994d.png)](https://cta-redirect.hubspot.com/cta/redirect/4021582/ae4c2301-80fc-441f-8f61-49b42722994d) ### When to Use an Isolation Ring Isolation rings are used primarily for sludges and slurries that would otherwise clog the cavities of a diaphragm seal. While diaphragm seals may primarily be used for corrosion concerns, isolation rings are used to prevent clogging. Although isolation rings operate much like a diaphragm seal, the design is much better suited to deal with abrasive particulates in a process. The sensing elements (also referred to as liners or bladders) can range from being more chemically resistant (such as PTFE) to more durable like Buna or natural rubber. These materials better withstand the continuous impact of particulate pushing through the piping. Isolation rings can be threaded or flanged into the process. When flanged, they can either be designed with bolt holes (lug style) that line up with the piping flanges or wafer style, which would be sandwiched between the two flanges. More importantly, isolation rings can range in size from ½-inch piping up to 36 or more inches. The larger the isolation ring, the more difficult the installation and the more expensive the eventual repair/replacement will be. *Figure 2: Three styles of isolation rings. * ![Isolation Ring Composite-small](https://blog.ashcroft.com/hs-fs/hubfs/Isolation%20Ring%20Composite-small.jpg?width=298&height=335&name=Isolation%20Ring%20Composite-small.jpg) ### Removing isolation rings can be a challenge. Regardless of the size, removing the isolation ring is not easy. At a minimum, the process would have to be shut down while the piping is cleaned, and the flange is dismantled. For repairs, the isolation rings would have to be properly cleaned and sanitized before being sent off for recalibration, system fluid refill or any other typical maintenance. Some manufacturers provide ways to disconnect the instruments from the isolation rings without compromising the system fill. Ashcroft offers the [Safe Quick Release™ (SQR™)](https://www.ashcroft.com/products/pressure/diaphragm-seals-and-isolators/?pageNumber=1&postTypes=product&postsPerPage=12&sortType=menu_order&sortOrder=ASC&tax-pa_seal-features=1302) feature that has a dry break coupling that allows the removal of the instrument without losing fill fluid. In these cases, regular maintenance is required, and consistent upkeep of equipment is very important. Some systems are designed with isolation rings, while others exclusively use diaphragm seals exposing their assemblies to the risk of clogging. It’s vital to make sure you are using the right equipment to meet your needs. ## Recommendations for Choosing Which Instrument to Use When helping customers select the right equipment, Ashcroft looks at it from an overarching application perspective to determine whether an isolation ring or diaphragm seal is best. Factors include many moving parts, including: - How the equipment is being installed - The size and concentration of particulates - The composition of media - The system pressure and temperature (isolation rings are limited in pressure and temperature) - The cost (Isolation rings tend to cost more than diaphragm seals, so using an isolation ring in a situation that doesn’t require it could be a waste of money). ### Diaphragm seal recommendations The [Ashcroft® 201 Threaded Diaphragm Seal](https://www.ashcroft.com/products/pressure/diaphragm-seal-isolators/200-201-diaphragm-seals/) protects pressure-measuring instruments when process compatibility is required. The diaphragm material in this style isolator is available in a large variation of metallic, elastomeric and fluoropolymer options. These are also applied when the media exhibits a mild potential to clog an instrument connection. Its continuous-duty design prevents process fluid loss in the event the measuring instrument is removed or fails. Figure 3: Ashcroft 201 threaded diaphragm seal ![100-200-300\_Seal\_Front](https://blog.ashcroft.com/hs-fs/hubfs/100-200-300_Seal_Front.jpg?width=234&height=234&name=100-200-300_Seal_Front.jpg) Other good diaphragm seal options include the[Ashcroft®](https://app.hubspot.com/blog/4021582/editor/111537439756/preview)[205 in-line saddle diaphragm seals](https://app.hubspot.com/blog/4021582/editor/111537439756/preview), which are welded directly onto process piping to prevent process clogging or accumulation, or the [Ashcroft® 206 in-line flanged diaphragm seals](https://www.ashcroft.com/products/pressure/diaphragm-seal-isolators/206-inline-flanged-diaphragm-seal/), which are mounted in-line with the process piping for applications where continuous flow is required to prevent clogging. These options can be more cumbersome for installation, and slightly more costly but are good fits for both chemical compatibility as well as clogging concerns. ### Isolation ring recommendations The [Ashcroft® 82 Threaded Isolation Ring](https://www.ashcroft.com/products/pressure/diaphragm-seals/isolators/82-threaded-isolation-ring/) is threaded in-line with process piping. It is designed for threaded piping systems to protect pressure-measuring instruments by eliminating process accumulation for more accurate readings. Although very limited with corrosion resistance they are a very economical approach to avoid clogging. Smaller facilities may tap off larger pipes with smaller 1-inch or 2-inch piping and use an 82 series isolation ring for their instruments. Figure 4: Ashcroft 82 threaded isolation ring ![Type82\_ISO\_Ring\_C](https://blog.ashcroft.com/hs-fs/hubfs/Type82_ISO_Ring_C.jpg?width=262&height=261&name=Type82_ISO_Ring_C.jpg) ### NSF 61 recommendations.  If your application involves potable water, any instruments you use in your system must be NSF/ANSI/CAN 61-certified for public safety. In this case, you will want to use the [Ashcroft® 200/201 Threaded Diaphragm Seals](https://www.ashcroft.com/products/pressure/diaphragm-seal-isolators/200-201-diaphragm-seals/) or the Stainless Steel/EPDM option of the [Ashcroft® 80, 81 and 82 Isolation Rings](https://www.ashcroft.com/products/pressure/diaphragm-seals-and-isolators/?pageNumber=1&postTypes=product&postsPerPage=12&sortType=menu_order&sortOrder=ASC&tax-pa_seal-features=1302), all of which are certified for use in potable water systems.   ## We don’t like to pressure you, but we have more information.  Now that you understand the situations where you would use a diaphragm seal vs. an isolation ring, you can choose the best solution for your application and help protect your instruments from clogging or corrosion. If you want more information on mounting accessories and assemblies, you can view our webinar about [pressure instrument mounting assemblies](https://sales.ashcroft.com/expert_guide_to_instrument_assemblies_webinar) or download our [Complete Guide to Pressure Instrument Assembly](https://sales.ashcroft.com/complete-assembly-guide). We also have a few related blog articles that offer : - [Why Use a Flushing Connection on a Diaphragm Seal?](https://blog.ashcroft.com/flushing-connection-on-diaphragm-seal) - [When to Use a Welded Instrument Assembly](https://blog.ashcroft.com/when-to-use-welded-instrument-assembly) - [Best Practices for Installing Flanged Diaphragm Seals](https://blog.ashcroft.com/installing-flanged-diaphragm-seals) - [What’s the Right Pressure Instrument Mounting Assembly for Me?](https://blog.ashcroft.com/pressure-instrument-mounting-assemblies) - [Isolation Ring Assemblies for the Water/Wastewater Industry that are Accurate and Reliable](https://blog.ashcroft.com/isolation-ring-assemblies-for-water-wastewater) Feel free to [contact us](https://sales.ashcroft.com/contact-us-question) with any questions or concerns. Our industry experts at Ashcroft can help answer your questions and get you on the right track! In the meantime, feel free to download our [Water and Wastewater Industry Solutions Guide](https://sales.ashcroft.com/water-wastewater-solutions-guide?_ga=2.27789369.420603002.1662467447-1727663658.1617109357).  [![Water and Wastewater Industry Solutions](https://no-cache.hubspot.com/cta/default/4021582/ae4c2301-80fc-441f-8f61-49b42722994d.png)](https://cta-redirect.hubspot.com/cta/redirect/4021582/ae4c2301-80fc-441f-8f61-49b42722994d) [Hope Karimi-Sheumaker, Territory Sales Manager](https://blog.ashcroft.com/author/hope-karimi-sheumaker) Hope Karimi-Sheumaker is the Territory Sales Manager (Channel/Distribution) at Ashcroft, responsible for 8 ½ states in the West, Southwest and mountain region. She started her career at Ashcroft in 2018 with 25+ years of experience in the fields of Instrumentation, Filtration, and Valve automation, with a strong focus on process. She enjoys working with distributors, EPCs, and end-customers in many areas including water/wastewater, oil and gas, food and beverage, high purity, and pharmaceutical to name a few, with a focus on providing solutions. In her off time, she enjoys outdoor activities with her family, fostering fur babies and leisure travel, especially cruises. Connect: [mailto:hope.karimi@ashcroft.com](mailto:hope.karimi@ashcroft.com) Topics: [Isolation Rings](https://blog.ashcroft.com/topic/isolation-rings) [water & wastewater](https://blog.ashcroft.com/topic/water-wastewater) [diaphragm seals](https://blog.ashcroft.com/topic/diaphragm-seals) Don't forget to share this post: ## Related Articles ### [![](https://blog.ashcroft.com/hs-fs/hubfs/UseCase_8-24-26_O%26G.BLOG.jpg?width=1600&height=534&name=UseCase_8-24-26_O%26G.BLOG.jpg) Solving Seal Reliability Challenges in Critical Instrument Applications August , 2026|2 min. read](https://blog.ashcroft.com/solving-seal-reliability-challenges-in-critical-instrument-applications) ### [![Pressure and Temperature Instruments for Phosgene Service](https://blog.ashcroft.com/hs-fs/hubfs/502%EF%80%A23_Phosgene_BLOG.jpg?width=1600&height=534&name=502%EF%80%A23_Phosgene_BLOG.jpg) What to Know About Pressure and Temperature Instruments for Phosgene Service July , 2026|5 min. read](https://blog.ashcroft.com/-pressure-and-temperature-instruments-for-phosgene-service) ### [![Premature Gauge Failure in a Water Treatment Pump System](https://blog.ashcroft.com/hs-fs/hubfs/UseCase_4-12-26.BLOG.jpg?width=1600&height=534&name=UseCase_4-12-26.BLOG.jpg) Diagnosing Premature Gauge Failure in a Water Treatment Pump System April , 2026|3 min. read](https://blog.ashcroft.com/diagnosing-premature-gauge-failure-in-a-water-treatment-pump-system) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/SaddleConnect_BLOG_V1.jpg?width=1600&height=534&name=SaddleConnect_BLOG_V1.jpg) Why Use a Saddle Seal in Process Applications? January , 2026|4 min. read](https://blog.ashcroft.com/why-use-a-saddle-connection-in-pressure-gauge-applications) ### [![Diaphragm Seal Certifications](https://blog.ashcroft.com/hs-fs/hubfs/Certs_Seals_BLOG_V1.jpg?width=1600&height=534&name=Certs_Seals_BLOG_V1.jpg) What Certifications are Available for Diaphragm Seal Assemblies? January , 2026|5 min. read](https://blog.ashcroft.com/what-certifications-are-available-for-diaphragm-seal-assemblies) ### [![Stainless steel vs Brass Material Compatibility](https://blog.ashcroft.com/hs-fs/hubfs/1008_Brs-SS_BLOG_V1.jpg?width=1600&height=534&name=1008_Brs-SS_BLOG_V1.jpg) Why Material Compatibility Matters When Replacing Pressure Instrumentation December , 2025|4 min. read](https://blog.ashcroft.com/why-material-compatibility-matters-when-replacing-pressure-instrumentation) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/LowPrAssembly_BLOG_V2.jpg?width=1600&height=534&name=LowPrAssembly_BLOG_V2.jpg) Choosing Assemblies for Low-Pressure Applications October , 2025|5 min. read](https://blog.ashcroft.com/choosing-assemblies-for-low-pressure-applications) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/1279w-ISO_BLOG_V1.jpg?width=1600&height=534&name=1279w-ISO_BLOG_V1.jpg) Why Field Filling Your Isolators is Not Recommended September , 2025|4 min. read](https://blog.ashcroft.com/why-field-filling-your-isolation-devices-is-not-recommended) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/Repost-T6500_XRABLOG_V1.jpg?width=1600&height=534&name=Repost-T6500_XRABLOG_V1.jpg) Best Pressure Gauges with Overpressure Protection July , 2025|3 min. read](https://blog.ashcroft.com/blog/best-pressure-gauges-for-overpressure-protection) ### [![Removing a pressure instrument from an isolator](https://blog.ashcroft.com/hs-fs/hubfs/Repost-SQR.BLOG_V2.jpg?width=1600&height=534&name=Repost-SQR.BLOG_V2.jpg) Can You Safely Remove a Pressure Instrument from an Isolator? May , 2025|3 min. read](https://blog.ashcroft.com/safely-remove-instrument-from-isolator) ### [![Diaphragm seals for low pressure applications](https://blog.ashcroft.com/hs-fs/hubfs/Low-Press-DS_Blog-1.jpg?width=1600&height=534&name=Low-Press-DS_Blog-1.jpg) Considerations for using a diaphragm seal in low-pressure applications April , 2025|5 min. read](https://blog.ashcroft.com/using-diaphragm-seals-in-low-pressure-applications) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/FlushPort_Seal_BLOG_V2.jpg?width=1600&height=534&name=FlushPort_Seal_BLOG_V2.jpg) Why Use a Flushing Connection on a Diaphragm Seal? March , 2025|2 min. read](https://blog.ashcroft.com/flushing-connection-on-diaphragm-seal) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/NoISO_BLOG_V1.jpg?width=1600&height=534&name=NoISO_BLOG_V1.jpg) When NOT to Use An Isolation Ring January , 2025|4 min. read](https://blog.ashcroft.com/when-not-to-use-an-isolation-ring) ### [![Why use a diaphragm seal or isolation ring](https://blog.ashcroft.com/hs-fs/hubfs/Repost-SEAL%EF%80%A2ISO_BLOG.jpg?width=1600&height=534&name=Repost-SEAL%EF%80%A2ISO_BLOG.jpg) Why Should You Use a Diaphragm Seal or Isolation Ring? November , 2024|6 min. read](https://blog.ashcroft.com/reasons-to-use-diaphragm-seal-isolation-ring) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/WWSeal_BLOG_RevA_V1.jpg?width=1600&height=534&name=WWSeal_BLOG_RevA_V1.jpg) What to consider when choosing material for your diaphragm seal September , 2024|5 min. read](https://blog.ashcroft.com/choosing-material-for-your-diaphragm-seal) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/Pressure%20Switch%20Tank%20Level_BLOG.png?width=1600&height=534&name=Pressure%20Switch%20Tank%20Level_BLOG.png) Can Pressure Switches Be Used to Monitor and Control Tank Level Pressure? August , 2024|4 min. read](https://blog.ashcroft.com/pressure-switches-for-water-level-managements) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/RepostOptimWW_BLOG_RevA_V1.jpg?width=1600&height=534&name=RepostOptimWW_BLOG_RevA_V1.jpg) How to Optimize Water & Wastewater Monitoring Instruments August , 2024|4 min. read](https://blog.ashcroft.com/blog/how-to-optimize-water-wastewater-monitoring-instruments) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/Basics.BLOG_8-7-24.jpg?width=1600&height=534&name=Basics.BLOG_8-7-24.jpg) Understanding NSF 61 Approvals for Pressure Instruments August , 2024|4 min. read](https://blog.ashcroft.com/understanding-nsf-ansi-61) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/PumpSys_BLOG_RevA_V2-1.jpg?width=1600&height=534&name=PumpSys_BLOG_RevA_V2-1.jpg) Protecting Pressure Instruments in Suction and Discharge Installations August , 2024|4 min. read](https://blog.ashcroft.com/protecting-instrumentation-during-suction-discharge-installations) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/InstrProt_VO1_BLOG_RevA_V1.jpg?width=1600&height=534&name=InstrProt_VO1_BLOG_RevA_V1.jpg) Protecting Instrumentation During Pipeline Hydrostatic Testing July , 2024|3 min. read](https://blog.ashcroft.com/protecting-instrumentation-during-hydrostatic-testing) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/Corrosion_Seal_BLOG_RevA_V1.jpg?width=1600&height=534&name=Corrosion_Seal_BLOG_RevA_V1.jpg) How to protect pressure instruments from different types of corrosion July , 2024|5 min. read](https://blog.ashcroft.com/protecting-instruments-from-corrosion) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/Repost-Basics.BLOG_Submersible.jpg?width=1600&height=534&name=Repost-Basics.BLOG_Submersible.jpg) What is a Submersible Pressure Transmitter and How Does it Work? May , 2024|4 min. read](https://blog.ashcroft.com/what-is-a-submersible-pressure-sensor) ### [![](https://blog.ashcroft.com/hs-fs/hubfs/FlangeSeal_BLOG_RevA_V1.jpg?width=1600&height=534&name=FlangeSeal_BLOG_RevA_V1.jpg) Best Practices for Installing Flanged Diaphragm Seals May , 2024|3 min. read](https://blog.ashcroft.com/installing-flanged-diaphragm-seals) ### [![Accurate, reliable isolation ring assemblies](https://blog.ashcroft.com/hs-fs/hubfs/Repost-ISO-Assem_BLOG.jpg?width=1600&height=534&name=Repost-ISO-Assem_BLOG.jpg) Why Are Isolation Ring Assemblies Used in Water/Wastewater Applications? April , 2024|4 min. read](https://blog.ashcroft.com/isolation-ring-assemblies-for-water-wastewater) ![https://f.hubspotusercontent30.net/hubfs/4021582/assets/images/ashcroft-logo-white.svg](https://blog.ashcroft.com/hubfs/assets/images/ashcroft-logo-white.svg) 250 East Main Street Stratford, CT 06614 [800.328.8258](tel:+1800.328.8258) [Contact](https://www.ashcroft.com/contact/) [Learning Center](https://www.ashcroft.com/learn/resource-center) [Blog](https://blog.ashcroft.com/) [Subscribe to Blog](https://sales.ashcroft.com/ashcroft-blog-subscribe) [Facebook](https://www.facebook.com/AshcroftInc) [Instagram](https://www.instagram.com/ashcroftinc/) [LinkedIn](https://www.linkedin.com/company/ashcroft-inc-/) [YouTube](https://www.youtube.com/user/AshcroftInc) [PRODUCTS](https://www.ashcroft.com/products) - [Pressure Instruments](https://www.ashcroft.com/products/#pressure) - [Temperature Instruments](https://www.ashcroft.com/products/#temperature) - [Test Instruments](https://www.ashcroft.com/products/#test-instruments) - [Product Configurator](https://www.ashcroft.com/product-configurator/) - [Product Documentation](https://www.ashcroft.com/learn/product-documentation) - [Pressure Gauge Selection Tool](https://www.ashcroft.com/pressure-gauge-selection-tool/) - [Product & Quality Certifications](https://www.ashcroft.com/about/quality-certifications/) PROCESS INDUSTRY - [Overview](https://www.ashcroft.com/solutions/process-industry-instrumentation/) - [Large Projects/EPC](https://www.ashcroft.com/solutions/process-industry-instrumentation/engineering-procurement-construction-large-projects/) - [Critical Application Solutions Experts (CASE)](https://www.ashcroft.com/solutions/process-industry-instrumentation/critical-application-solution-experts/) - [Distributor Locator](https://www.ashcroft.com/ashcroft-distributors/) INDUSTRIAL/OEM - [Overview](https://www.ashcroft.com/solutions/industrial-oem/) - [Custom Engineered Solutions (CES)](https://www.ashcroft.com/solutions/industrial-oem-custom-engineered-solutions/) COMPANY - [About](https://www.ashcroft.com/about/) - [Corporate Responsibility](https://www.ashcroft.com/about/corporate-responsibility/) - [Code of Conduct](https://www.ashcroft.com/about/corporate-responsibility/code-of-conduct/) - [Trade Compliance](https://www.ashcroft.com/about/corporate-responsibility/trade-compliance/) - [Product Stewardship](https://www.ashcroft.com/about/corporate-responsibility/product-stewardship/) - [Company News & Events](https://www.ashcroft.com/news-events/) - [Careers](https://www.ashcroft.com/careers/) - [Contact](https://www.ashcroft.com/contact/) © 2026 Ashcroft Inc.. All Rights Reserved. [Privacy Statement](https://www.ashcroft.com/privacy-policy/) | [Legal Disclaimer](https://www.ashcroft.com/disclaimer) | [Supplier Terms of Purchase](https://www.ashcroft.com/wp-content/uploads/2026/07/ashcroft-purchase-order-terms-conditions-revh-july26.pdf) | [Terms of Sales](https://www.ashcroft.com/wp-content/uploads/2023/08/terms-of-sale-ashcroft.pdf) | [Privacy Policy](https://www.ashcroft.com) ```json { "@context" : "https://schema.org", "@id" : "https://blog.ashcroft.com/#website", "@type" : "WebSite", "inLanguage" : "en-US", "name" : "Ashcroft Inc.", "potentialAction" : { "@type" : "SearchAction", "query-input" : "required name=search_term_string", "target" : "https://blog.ashcroft.com/search?term={search_term_string}" }, "publisher" : { "@id" : "https://blog.ashcroft.com/#organization" }, "url" : "https://blog.ashcroft.com" } ``` ```json { "@context" : "https://schema.org", "@id" : "https://blog.ashcroft.com/#organization", "@type" : "Organization", "address" : { "@type" : "PostalAddress", "addressCountry" : "US", "addressLocality" : "Stratford", "addressRegion" : "CT", "postalCode" : "06614", "streetAddress" : "250 East Main Street" }, "image" : { "@id" : "https://blog.ashcroft.com/#logo" }, "logo" : { "@id" : "https://blog.ashcroft.com/#logo", "@type" : "ImageObject", "caption" : "Ashcroft Logo", "contentUrl" : "https://4021582.fs1.hubspotusercontent-na1.net/hubfs/4021582/social-suggested-images/sales.ashcroft.comhs-fshubfsashcroft-logo-lg-2.png", "height" : 45, "inLanguage" : "en-US", "url" : "https://4021582.fs1.hubspotusercontent-na1.net/hubfs/4021582/social-suggested-images/sales.ashcroft.comhs-fshubfsashcroft-logo-lg-2.png", "width" : 200 }, "name" : "Ashcroft Inc.", "sameAs" : [ "https://www.facebook.com/AshcroftInc", "https://www.instagram.com/ashcroftinc/", "https://www.linkedin.com/company/ashcroft-inc-/", "https://www.youtube.com/user/AshcroftInc" ], "telephone" : "+18003288258", "url" : "https://blog.ashcroft.com" } ``` ```json { "@context" : "https://schema.org", "@type" : "BlogPosting", "author" : { "@type" : "Person", "name" : "Hope Karimi-Sheumaker, Territory Sales Manager", "url" : "https://blog.ashcroft.com/author/hope-karimi-sheumaker" }, "dateCreated" : "2023-04-18T13:25:42", "datePublished" : "2024-10-23T11:25:32-0400", "description" : "Learn when to use diaphragm seals versus isolation rings to protect your instruments from clogging and corrosion in various industrial applications.", "headline" : "When to Use a Diaphragm Seal vs. an Isolation Ring", "image" : [ "https://4021582.fs1.hubspotusercontent-na1.net/hubfs/4021582/Seal_ISO_2024_BLOG_V2.jpg" ], "inLanguage" : "en", "keywords" : [ "Isolation Rings", "water & wastewater", "diaphragm seals" ], "learningResourceType" : "article", "name" : "When to Use a Diaphragm Seal vs. an Isolation Ring", "publisher" : { "@type" : "Organization", "logo" : { "@type" : "ImageObject", "url" : "https://4021582.fs1.hubspotusercontent-na1.net/hubfs/4021582/social-suggested-images/sales.ashcroft.comhs-fshubfsashcroft-logo-lg-2.png" }, "name" : "Ashcroft Inc." }, "timeRequired" : "PT5M", "url" : "https://blog.ashcroft.com/diaphragm-seal-vs.-isolation-ring" } ```
